Description
Clamp Mounted Keyboard Tray with Storage Drawer
Family: Workspace Accessories Category: Keyboard Trays Color: Black
Add an adjustable keyboard and mouse surface at the desk edge. The tray combines a wrist support, a small storage drawer and a locking height mechanism, with mounting arrangements for use above or below the desktop.
Is This Right for You
For workspaces that need an adjustable input-device position and have a suitable desk edge for the mounting clamp.
Key Benefits
- The clamp attaches at the desk edge without requiring an under-desk mounting track.
- Height, tilt and swivel adjustments help set the input devices around the working position.
- A front wrist support and small drawer combine a working surface with storage for light desk items.
Compatibility and Installation
Check the desktop thickness, edge shape and clamp reach before ordering; the desk must resist the clamp and working loads. Allow the complete movement path and knee clearance, and compare the keyboard plus mouse area with the 635 x 270 mm platform.
Specifications and Adjustment
| Specification | Details |
| Keyboard platform | 635 x 270 mm |
| Overall assembly dimensions | 635 x 372 x 169 mm |
| Maximum combined load | 5 kg |
| Tilt | 5 degrees upward to 20 degrees downward |
| Swivel | 180 degrees in either direction |
| Height setting | Manual locking handle; confirm endpoints for the installation |
| Mounting | Desk clamp; above-desktop or below-desktop arrangement |
| Materials | Steel, MDF and plastic |
| Color and pack | Black; standard version |
Materials and Construction
A powder-coated steel mechanism supports an MDF platform with plastic components. Protective clamp pads separate the mount from the desk surface, but the desk finish and construction still need to be suitable for clamping.
Setup and Everyday Use
- Select the above-desk or below-desk arrangement using the supplied assembly guide.
- Attach the clamp to a suitable edge and check that both contact faces sit correctly.
- Support the platform while setting height and tilt, then secure the locking handle.
- Place the devices and check swivel, knee clearance, drawer access and cable slack.
Limitations
The 5 kg limit applies to the combined supported load, including anything placed in the drawer. Do not treat it as a monitor shelf or lean on it to rise from the chair. Clamp thickness limits and absolute height endpoints need to be matched to the supplied configuration.
Package and Mounting Options
One black clamp-mounted keyboard tray with wrist support and storage drawer. Confirm the order-specific assembly fittings and packing dimensions.
Installation Guidance and Warranty
Contact JIANVO for the matching installation or care instructions, spare-part availability and warranty terms applicable to your order.
Bulk Orders and Customization
Send JIANVO the product code, quantity, delivery destination and packaging requirements. Availability, lead time and customization are subject to quotation.
Frequently Asked Questions
Can it be used above the desktop? Yes. Above-desk and below-desk arrangements are described; follow the matching assembly instructions.
Does the compact-pack version have a smaller keyboard surface? No. Both listed versions use a 635 x 270 mm platform and the same published assembled dimensions.
Can I adjust it while typing? Support the platform and stop typing before releasing or locking an adjustment.
Alternative Jianvo Products
Compare these Jianvo products for the same task. Check device compatibility and installation requirements before switching.
| Jianvo product | Shared purpose | When to choose it |
| JNV-KBT-054-01 | Same clamp-mounted keyboard function | Choose the compact packaging version; confirm its packing and assembly requirements. |
| JNV-KBT-051-01-B | Adjust the keyboard working position | Choose an under-desk sliding track and extending mouse area instead of the desk-edge clamp. |
